HW-OMNI-D4111

The HW-OMNI-D4111 is a networked AV decoder for HDMI/HDCP 2.2 output supporting resolutions up to 4K/60 4:4:4 and HDR, plus audio embedding and de-embedding, and RS-232 or IR control pass-through. Powered by the advanced VCx™ codec, it delivers 4K/60 4:4:4 from encode to decode with artifact-free presentation and ultra-low latency of less than one frame. Multiview processing enables up to four streams from HW-OMNI-E4111 encoders to be displayed simultaneously on a single screen. The HW-OMNI-D4111 is housed in a half-width rack enclosure with front-to-back airflow, and supports PoE powering for simplified installation.

Features

• 4K/60 4:4:4 encode with VCx™ codec — artifact-free image quality and ultra-low latency (<1 frame).

• HDR support: HDR10, HLG, and Dolby® Vision™ at 60 Hz.

• Single decoding engine with integrated high-performance scaler (up to 4K/60).

• Multiview window processing — ingests up to 4 streams simultaneously on one screen

• HDCP 2.2 compliant; AES-128 encrypted stream delivery.

• CEC, RS-232, and IR control pass-through over the network.

• PoE (IEEE 802.3af) powered — no local AC required; optional 48V external supply.

• IEEE 802.1x network authentication; HTTPS, SSH, Telnet, WebSocket/TLS management.

• AES67-compatible audio; simultaneous OmniStream and AES67 streaming.

• Thumbnail preview of encoded streams (320×180px, 2-second update) for source monitoring.

• Half-width rack enclosure with front-to-rear temperature-controlled airflow.

• NDAA Section 889 and TAA compliant.

Applications

Enterprise AV Distribution

• Distribute 4K/60 AV content across corporate networks to any connected display, enabling flexible room-to-room and campus-wide sharing.

Higher Education

• Deploy decoders in classrooms and overflow rooms to receive broadcast content from lecture capture encoders over standard Gigabit Ethernet.

Control Rooms & Operations Centers

• Use Multiview processing to display up to four encoded streams simultaneously on a single screen for monitoring and situational awareness.

Hospitality & Public Venues

• Deliver pristine 4K content to displays throughout hotels, stadiums, and venues over existing network infrastructure.
